tesa® 50600 Green Masking Powder Coating Tape – 50mm x 66m Roll
£16.85
The tesa® 50600 is a specialized masking tape designed for high-temperature applications, particularly in powder coating processes. This report synthesizes key points from various sources to provide a comprehensive overview of the product’s features, applications, and specifications. Product-information_tesa®-50600_en-GB.pd
High-Temperature Resistance
The tesa® 50600 tape is renowned for its ability to withstand extreme temperatures. It can endure up to 220°C (428°F) for 30 minutes, making it suitable for high-temperature applications such as powder coat featuring a polyester backing with a silicone adhesive
Available in Packs of 36 Rolls
BUYING MORE THAN 5 BOXES? BULK DISCOUNTS AVAILABLE ON REQUEST
Description
tesa® 50600 is a green, high-temperature masking tape featuring a polyester backing with a silicone adhesive.
Features and benefits include:
– Easy to apply
– High temperature resistance – up to 220°C / 428°F (30min.)
– One piece removal without leaving residues
Main applications
For masking off areas that are not to be coated during powder coating process.
Material Composition
The tape features a polyester (PET) backing combined with a silicone adhesive. This combination provides durability and high-temperature resistance, essential for industrial applications.
Easy Application and Removal
One of the standout features of tesa® 50600 is its ease of application and removal. The tape can be applied smoothly and removed in one piece without leaving any residue, which is crucial for maintaining clean surfaces during and after the coating process.
Sharp Color Edges
The tape enables sharp color edges, which is particularly important in applications requiring precise paint lines and high-quality finishes.
Applications
Powder Coating
The primary application of tesa® 50600 is in masking areas that should not be coated during the powder coating process. Its high-temperature resistance and clean removal make it ideal for this purpose.
Bonding and Splicing
The tape is also used in bonding and splicing applications, particularly with non-polar materials. Its strong adhesive properties ensure that materials are held securely in place.
Surface Protection
In addition to masking, tesa® 50600 is used for surface protection applications. It protects surfaces from damage during various industrial processes and can be removed cleanly without leaving residues.
Composite Manufacturing
The tape is employed in holding layers of film and fabric in place during the composite manufacturing process. It is also used for temporary holding during the bonding of various composite materials and metals.
Specifications
Physical Properties
- Total Thickness: The tape has a total thickness ranging from 2.76 mils (70 µm) to 3.1 mils.
- Elongation at Break: The tape can elongate up to 110% before breaking, providing flexibility during application.
- Tensile Strength: It has a tensile strength of approximately 42.8 lbs/in (75 N/cm), ensuring durability and resistance to tearing.
- Dielectric Breakdown Voltage: The tape can withstand up to 4000 V, making it suitable for electrical insulation applications.
Adhesive Properties
- Adhesion to Steel: The tape has an adhesion strength of 2.06 lbs/in (3.6 N/cm) to 36.5 oz/in, ensuring it sticks well to various surfaces.
- Type of Adhesive: The silicone adhesive provides excellent heat resistance and clean removal properties.
Conclusion
The tesa® 50600 Green Masking Powder Coating Tape is a versatile and high-performance tape designed for demanding industrial applications. Its high-temperature resistance, ease of application and removal, and ability to create sharp color edges make it an essential tool in powder coating, bonding, splicing, and surface protection tasks. The tape’s robust physical and adhesive properties further enhance its suitability for various industrial processes.
